TGM5 series moulded case circuit breakers are divided into C-type, L-type, M-type, H-type, and S-type according to their rated ultimate short-circuit breaking capacity (ICU), and it is an ideal product for power distribution and motor protection. With the rated insulation voltage up to 1250V, it is used in the AC 50/60Hz circuit with the rated operating voltage 690V and below and with the rated current from 125A to 500A for infrequent conversion of the line and infrequent start of the motor.
