LXW5 series micro switch is suitable for AC 50Hz control line with a rated voltage up to 380V or with a DC voltage up to 220V for travel control, interlocking and limit protection of various mechanical devices.
Inquiry
Certificate
| Model | Rated voltage (V) | Rated control capacity | Resistive current (A) |
| LXW5 | AC380、220、110 | AC100VA | 3 |
| DC220、110、24 | DC10W |
Normal operation and installation conditions:
1.1 Ambient temperature: -5℃ ~+40℃ .
1.2 Altitude: Not exceed 2000m.
1.3 Atmospheric conditions: The relative humidity does not exceed 50% when the ambient temperature is +40℃ ; higher relative humidity is allowed at a lower temperature. The mean maximum relative humidity of the wettest month is 90%, and the mean month minimum temperature of this month is +25℃ , and condensation on the product surface due to temperature changes shall be considered.
1.4 Pollution level: 3.
1.5 Installation category: Class III, mounted at any angle.
