TGB3-OF2 auxiliary contact is used in the AC 50/60Hz line with the appointed heat current up to 6A, with rated voltage up to 415V or DC rated voltage up to 130V, and is mainly assembled with the TGB3 series miniature circuit breaker with shell frame current 125A and with the residual current action circuit breaker with shell frame current 63A for remote circuit breaker ON/OFF signal indication
Inquiry
Certificate
| Working voltage | AC-12 | Ue=AC415V |
| Ue=AC240V | ||
| DC-12 | Ue=DC130V | |
| Ue=DC48V | ||
| Ue=DC24V | ||
| Working state | 11：Common end Product opening：11、14 disconnect；11、12 connect Product closing：11、14 connect；11、12 disconnect | |
| Mechanical life | 6050 times | |
| Max. wiring area (mm²) | 2.5 | |
| Installation | Installed after assembling with circuit breaker | |
| Use category | AC12DC12 | |
